CPFS/D USB™ spirometer

Spirometry

CPFS/D USB™ spirometer

When you need full-function spirometry and space is at a premium, the CPFS/D USB™ spirometer is a most fitting solution. This small, portable system may look unassuming, but it’s packed with technological advances and features to meet all of your testing and data management needs. The CPFS/D USB spirometer is compatible with desktop and laptop computers for maximum flexibility. It has incentive graphs for spirometry, which are ideal for pediatric populations. And like all MGC Diagnostics pulmonary function testing products, the CPFS/D USB spirometer  incorporates our BreezeSuite™ cardiopulmonary diagnostic software and the same preVent® flow sensor—so you can always be assured of accurate, reliable data comparisons from test to test.

>  download (pdf):  CPFS/D USB™ spirometer

TEST PERFORMED
Pre/post FVC, SVC, MVV and challenge (with optional bronchial provocation software)

PREDICTED NORMALS
BreezeSuite™ cardiopulmonary diagnostic software contains over 30 authors, the most extensive list of predicted formulas available, including NHANES III.

EASY-TO-USE BREEZESUITE™ CARDIOPULMONARY DIAGNOSTIC SOFTWARE
  • Ease of use allows operator to focus on patient's effort.
  • Timely prompts guide the operator through the entire testing process.
  • Powerful Microsoft® SQL database provides flexibility in accessing, manipulating and reporting data.
  • Automated quality-assurance program notifies operator to ensure results comply with ATS/ERS acceptability criteria.
  • BreezeSuite™ cardiopulmonary diagnostic software allows physicians to access data and interpret patient results from any computer that has permission to access the facility network (VPN).

INTERPRETATION
Optional pulmonary consult interpretation software allows for an immediate computerized assessment of testing results.

preVent® FLOW SENSOR FOR SIMPLICITY AND ACCURACY

  • Eliminates warm-up or recalibration between patients
  • Contains no moving parts or electronics for cost-effective testing
  • Options to use with a filter, sterilize or discard


TREND REPORTS
Trend reports allow printing and graphing data from previous patient visits so that progress can be monitored.

DATABASE QUERY
Queries of the patient database can be performed for quality control or particular sets of patients.

BRONCHIAL PROVOCATION
Optional software is available for methacholine, mannitol, exercise or cold-air challenges.

NETWORK CAPABLE
With the addition of BreezeSuite MultiUser™ networking software, the system may be added to a local or wide area network.

OPTIONAL BREEZECONNECT™ HL7 INTERFACE SOFTWARE

  • Electronic medical record interface using latest HL7 standards with either unidirectional or bidirectional capability
  • Flexible access allows physicians to view and interpret patient results from any location on the facility’s network

PERFORMANCE SPECIFICATIONS
The system consists of a flow module containing the transducers and electronics to produce a bidirectional flow signal with the MGC Diagnostics preVent® flow sensor.





Contact the MGC Diagnostics Sales Support Team for additional configuration information or to place an order:
> phone: +1 651.484.4874 or 800.655.1133      > fax: +1 651.484.8941      > email: salesservices@mgcdiagnostics.com
Test Modes (standard)
  • Spirometry Pre/Post: FVC, SVC, MVV
  • ABG: Arterial Blood Gas Entry
​Additional Test Mode (optional)
  • Bronchial Provocation
Software Features (standard)
  • ATS/ERS Error Codes
  • Disability Reports
  • HIPAA/HITECH Security
  • Manual Data Entry
  • Microsoft® SQL Database
  • Pediatric Incentives
  • Report Designer
  • Trend Reports
  • User-Defined Predicteds
Additional Software Features (optional)
  • BreezeConnect™ HL7 interface software
  • BreezeReview™ physician review software
  • BreezeSuite MultiUser™ networking software
  • BreezeSuite WebReview™ physician review software
  • Pulmonary Consult™ physician interpretation software
  • Database Query
  • Electronic Signature
  • Quality Control Query



Contact the MGC Diagnostics Sales Support Team
to request a supply quote, or for volume discount pricing: > phone: +1 800.655.1133 Option 1      > fax: +1 651.379.8285      > email: supplies@mgcdiagnostics.com
to place and order: > phone: +1 800.655.1133 Option 2      > fax: +1 651.484.8941      > email: orders@mgcdiagnostics.com
download (pdf): > supplies        > patient testing supplies

MGC Diagnostics' supplies are the only recommended supplies for use with MGC Diagnostics equipment to achieve accurate, validated
test results that meet ATS and ERS standards.

kits
  Kit 1
contains: preVent II filter (536713-002)
& Nose Clip (536007-003
)
PN: 536719-001
> qty: 100 per box
  Kit 2
contains: preVent II filter (536713-002), Nose Clip (536007-003) & Mouthpiece (536006-004)
PN: 536723-001
> qty: 100 per box

mouthpiece and adapter
  Small (use with preVent flow sensor​)
PN: 536006-003
> qty: 10 per pack
  Medium (use with preVent flow sensor​)
PN: 758300-001
> qty: 50 per pack
  Medium (use with preVent filter​)
PN: 536101-002
> qty: 10 per pack

  Medium (use with preVent flow sensor or preVent filter​)
PN: 536006-004
> qty: 100 per pack (disposable)
  Large (use with preVent flow sensor​)
PN: 536006-001
> qty: 10 per pack
  Pediatric (use with pediatric adapter
and rubber coupler​)

PN: 536006-002
> qty: 10 per pack

  Pediatric adapter (use with pediatric
mouthpiece and rubber coupler​)

PN: 535082-001
> qty: 1 each


filter and pneumotach
  preVent II pulmonary function filter
oval mouthpiece with lip grip
PN: 536713-002
> qty: 100 per box
  preVent pulmonary function filter
round mouthpiece
PN: 536713-001
> qty: 100 per box
  preVent flow sensor
PN: 758100-004
> qty: 24 per pack

umbilical
  PN: 701066-021
> qty: 1 each

nose clip
  clear: padded
PN: 536007-003
> qty: 100 per pack (disposable)
  White: no pad
PN: 536007-001
> qty: 100 per pack (disposable)
  Parallel
PN: 536018-001
> qty: 100 per pack (disposable)

  Parallel-R
PN: 536019-001
> qty: each
each reusable clip comes with 10 pairs of replacement pads
  Replacement Pads, Parallel-R
PN: 536020-001
> qty: 100 pads (50 pairs)


rubber coupler
  PN: 536003-001
> qty: 1 each





Contact the MGC Diagnostics Sales Support Team for additional configuration information or to place an order:
> phone: +1 651.484.4874 or 800.655.1133      > fax: +1 651.484.8941      > email: salesservices@mgcdiagnostics.com
Test Modes (standard)
  • Spirometry Pre/Post: FVC, SVC, MVV
  • ABG: Arterial Blood Gas Entry
​Additional Test Mode (optional)
  • Bronchial Provocation
Software Features (standard)
  • ATS/ERS Error Codes
  • Disability Reports
  • HIPAA/HITECH Security
  • Manual Data Entry
  • Microsoft® SQL Database
  • Pediatric Incentives
  • Report Designer
  • Trend Reports
  • User-Defined Predicteds
Additional Software Features (optional)
  • BreezeConnect™ HL7 interface software
  • BreezeReview™ physician review software
  • BreezeSuite MultiUser™ networking software
  • BreezeSuite WebReview™ physician review software
  • Pulmonary Consult™ physician interpretation software
  • Database Query
  • Electronic Signature
  • Quality Control Query
